PixelDrop

Creative staging LED Curtain

Want some creative and innovation staging designs? PixelDrop is an option.

PixelDrop is a combination of LED lighting and LED video product. It is a creative LED solution for big staging, rental and permanent installation.

Product Description

Flexible and lightweight

There are 8 LED tubes of each string connected by flexible cables, and it is 2.4m long, 1.8kg in weight It is flexible to be concave and convex for varies innovative designs.

3 in 1 controller

The header includes power supply unit, receivers and hanging bar function, which power and signal come in and out from.

Fast assembling for big area.

The headers are with fast locking system to make it fast to install the LED screen.

High protection level with IP68 for outdoor environment.

Brompton control processor.

Brompton control system can match special LED screen installation to meet creative designs on stages.

Parameter

Item	Parameter
Model NO.	PixelDrop PD30
Pixel pitch	30mm
Brightness	2000 nits
Refresh rate	More than 3000Hz
Quantity of pixels per tube	4
Quantity of tube per string	8
Pixel pitch	30mm
Length of string	2.4m
Weight per string	1.8kg
Max. power consumption per string	60W / PCS
Ave. power consumption	25W / PCS
Colors	12bits
Viewing angle	360°
Protection level	IP68
Video source	DVI
Control system	Brompton
