Outdoor Fixed LED

Outdoor Fixed LED Display

FantaLED has a wide range of fixed outdoor LED display, and pixel pitch ranges from 2.5mm to 20mm. Cabinet dimension can be customized according to the project. Different cabinet materials are optional, like iron, aluminum and die-cast aluminum etc.

Product Description

Many Pixel Pitches for Options

There are many pixel pitches for options from 2.5mm to 20mm.

High Brightness and High refresh rate

Brightness on more than 6000nits, and refresh rate in 3840Hz

Customized Cabinet Size

Cabinet sizes can be customized according to specific information, which is closed to screen size for the project.

Tidy Cable Connection

Inner cables are neatly connected.

Waterproof IP65

It is waterproof in IP65 protection, and there is a brim to stop the water getting into the cabinet.

Parameter

Item	Parameter
Model No.	P2.5	P3	P4	P5	P6	P6.67	P8	P10
Pixel configuration	1R1G1B
LED type	SMD1415	SMD1415	SMD1921	SMD1921	SMD2727	SMD3535	SMD3535	SMD3535
Density（dots/m²）	160,000	111,111	62,500	40,000	27,777	22,500	15,625	10,000
Module size（mm）	320x160	192x192	256x128	320x160	192x192	320x160	256x128	320x160
Module resolution	128x64	64x64	64x32	64x40	32x32	48x24	32x16	32x16
Cabinet size（mm）	960x960	960x960	1024x1024	960x960	960x960	960x960	1024x1024	960x960
Module resolution	384x384	320x320	256x256	192x192	160x160	144x144	128x128	96x96
Scan method	1/16	1/16	1/8	1/8	1/8	1/6	1/4	1/2
Brightness（nits）	≥5,500	≥5,500	≥5,800	≥5,800	≥5,800	≥6,000	≥6,000	≥6,000
Refresh rate（Hz）	≥3840	≥3840	≥3840	≥3840	≥3840	≥3840	≥3840	≥3840
Frame frequency（Hz）	50&60
Color depth（bit）	12-16 adjustable
Weight（kg/m2）	44	44	44	44	44	44	44	44
Cabinet material	Steel or aluminum
Protection level	IP65 front, IP54 rear
Maintenance	Rear or front
